1.5. NOTIFICATIONS

1.5.1. STATUS LED
Two LED indicators located above the touch screen provide information about charging
status, scanner light beam, and scanner "Good Read" during data collection.
LED Indicators
Charging
Left
Scanner decode
Right Scanner beam
Note: For Scanner decode and Scanner beam LED to function, LED notification must be
enabled in Reader Configuration. See
1.5.2. AUDIO
The speaker is used to play sounds for events in Windows and programs, or play audio
files such as .WAV files. In addition, it can be programmed for status feedback. In noisy
environments, you may consider connecting a CTIA headset instead. A headset jack is
provided on the left side of the mobile computer, which is a 3.5 mm DIA stereo earphone
jack. The mobile computer also supports using Bluetooth headsets.
Go to Start Screen | Settings, and tap Sounds & Notifications to configure related
settings.
Chapter 1 Using the 9200 Mobile Computer
Status
Green, solid
Red, solid
Red, solid for 8 sec, then
flashing
Green, flash once
Orange, on while scan key
is pressed
Enable LED
Description
Charging complete
Charging the mobile computer
Charging error
battery not in place)
Good read
Scanner laser beam sent out
Notification.
(for instance,
25
