CipherLab 9200 Reference Manual page 153

9200 Mobile Computer Reference Manual
Display hex values
Timeout
WRITE BLOCKS SETTINGS
Setting
Write blocks
Login Key
Turn off RFID when
device suspend
Start byte to write
Display hex values
Timeout
Input string to write
Note: Refer to the specifications of the RFID tag to read for its memory organization.
138
Displays decoded data in hex values.
Generally the readable RFID data lies in a user
block. If the data to collect is located in a non-user
block such as the lock block, select Display hex
values in case the data to collect involves any
invisible character.
Sets the maximum time for decoding an RFID Tag
during a scan attempt. Configurable from 1-20 sec.
Descriptions
Writes data to an RFID tag
Shows what key A and key B currently is.
Keys A and B are what the RFID reader module
relies on to access (read or write) an RFID tag. In
default state, both keys are a sequence of twelve
"F" characters because they are Mifare tag's
factory default.
necessary.
Select this to turn off RFID function when device enters
suspension. Once the mobile computer is resumed
from suspension, RFID function will be automatically
restored.
Defines where to start writing data to.
See Appendix V:
Writes data in hex values.
Generally an RFID tag's writeable block lies in the
user block. However, if the block to write is a
non-user block such as the lock block, select Use
hex values to write data in hex values in case the
block to write involves any invisible character.
Sets the maximum time (configurable from 1 to 20
sec) for the decoding process during a scan attempt.
Defines what to write.
Note that different RFID tags may have different
default blocks (also "pages"), and different amount
of bytes and number of blocks. The data written
might be truncated to fit the blocks of the targeted
RFID tag. Therefore part of the data may be
discarded when it comes to the end of a block end.
See Appendix V:
Modify these default keys if
RFID Tag Default Block.
RFID Tag Default Block.
Deselected
3 sec
Default
Deselected
Key A &
FFFFFFFFFFFF
Deselected
-1 (default block,
byte 0)
Deselected
3 sec
--
