USE PING TOOLS
To perform ping tests, select Ping Tools in the drop-down bar.
Item Description
Destination Enter the address to ping.
Ping Payload The amount of data to be transmitted on a ping.
Ping Delay The amount of time that elapses between successive ping requests.
Timeout ms The amount of time that elapses without a response before ping request is
considered a failure.
Start Ping Enter the address to ping to in the Destination field and tap Start Ping. A
continuous ping will begin until the following happens: Stop Ping is tapped, the,
the application is exited, or the radio is removed. Activity status will be logged in
the output box below.
Value: 32, 64, 128, 256, 512, 1024
Default: 32 (bytes)
Value: 0~7200000
Default: 1000 (milliseconds)
Value: 0~30000
Default: 5000 (milliseconds)
Select Ping Tools to diagnose
the connection
Device IP address
AP Name
