Redundancy Level
Scan Angle
Scan Mode
Timeout Between Symbols Only available for Continuous mode. The default value is 1 sec.
2D IMAGER SETTINGS
Barcode Reader
2D Reader
Decode Session Timeout
Decode Illumination
Aiming Pattern
Sets how many successful readings should be done before linear
barcodes such as Codabar, MSI, and Interleaved 2 of 5 can be
decoded. Levels 1 to 4 available.
The readings needed for each level are as follows:
Level 1 The following barcodes must be successfully read
twice before being decoded: Codavar, MSI, Industrial
25 (Discrete 25), Interleaved 25.
Level 2 All barcodes must be successfully read twice before
being decoded.
Level 3 All barcodes must be successfully read twice before
being decoded, except for the following which must be
read three times: MSI, Industrial 25 (Discrete 25),
Interleaved 25.
Level 4 All barcodes must be successfully read three times
before being decoded.
Select the scan angle for Long Range Laser scan engine. Default is
"wide".
"wide" for 35°
"narrow" for 47°
Sets the reader's scanning behavior. Default is "Laser".
"Continuous" to decode the same barcode repeatedly or decode
different barcodes in a continuous motion.
"Laser" for scanning by pressing the scan trigger.
Description
The 2D scan engine is capable of reading linear and 2D barcodes.
Tap the Barcode Reader button to configure reader settings for the
2D scan engine.
Refer to the Reader Settings Table in Appendix IV -
(SE4500DL).
Sets the maximum time (configurable from 1 to 9 sec) for the
decoding process during a scan attempt. The default value is 3 sec.
Decide whether to flash illumination on every barcode capture to aid
decoding.
Turn on (internal LED)
Turn off
Decide whether to project the aiming pattern during barcode capture.
Turn on
Turn off
Chapter 7 Using Reader Configuration Utility
2D Imager
