Inserting Sim Card - CipherLab 9200 Reference Manual

9200 Mobile Computer Reference Manual

INSERTING SIM CARD

Inserting Card
Push down the clip on top of the battery cover to unlock it.
1.
Remove the battery cover as well as the battery.
2.
Insert SIM card into the SIM card slot as the icon engraved in the battery
3.
compartment shows. Push SIM card to lock it in.
Replace the battery cover. Fix the lower end first, then pull down the clip on top
4.
and press battery cover in until a 'click' is heard. Lock battery cover by pushing up
the clip.
Removing Card
Push down the clip on top of the battery cover to unlock it.
1.
Remove the battery cover as well as the battery.
2.
Push the SIM card. It will be ejected automatically for removal.
3.
Replace the battery cover. Fix the lower end first, then pull down the clip on top
4.
and press battery cover in until a 'click' is heard. Lock battery cover by pushing up
the clip.
6
