CVM k 2
6.2. DEMAND
On the
demand
screen, the user can select the
the desired fee from among all those that are configured.
If no tariff has been configured, number 1 will be chosen by default.
The following parameters are displayed for all tariff on the
p. total
s.Total
:
I1
I2
:
:
I3
:
I. AVG
On this screen, the following options are shown above the function buttons:
: This displays the system information screen (Section 6.1.1.1., System Information).
Info
: This displays the screen with the maximum values stored. The maximum values for each
Max
variable recorded since the last reset are displayed on the screen along with the date
and time of registry.
On the
Max
screen, the
that displays the instantaneous variables.
The maximum demand values stored in memory are displayed on the mAx
screen.
:
Total active power for the tariff.
:
Total apparent power for the tariff.
Phase 1 current
Phase 2 current
Phase 3 current
mean for the three phase currents.
INST.
option appears, which can be used to return to the screen
Demand
to be displayed. This corresponds to
screen.
demand
103
