4.7.1.3. Digital inputs configuration

The card inputs are also configured in two different ways depending on whether the user
desires to configure the input as an incremental counter or a two-state logic input (ON/Off).
= 0000
size
Accordingly, the input is configured as a two-state input, ON/Off. When the input is configured
as ON/Off, it is not necessary to configure the next menu option,
size ≠ 0000
When an input size other than zero is configured, this is configured as an incremental pulse
counter, which can have a maximum counter value of 10m. The value to enter is the multiplier
for each input pulse.
Dec. pos:
The options available in the lower menu include:
(f2).
Next
(f1):
OUT
To store the modified parameters in memory, press
saving changes press
44
WARNING: The value 00 in an outputs activation equation means that nothing at
all should be done. Thus, it should only be entered at the end of the equation. If
the value 00 is entered at the beginning of the equation, the CVMk2 will not make
the calculation or activate the corresponding output.
Indicate the decimal positions that the corresponding input counter should
have.
This increases the input number from 1 to a maximum of 08 to access its
configuration. from the 08 input configuration screen, pressing f2 (
will take the user back to the 01 input configuration screen.
Press this button to access the alarms configuration screen, Section 4.7.1.1.
(f3).
ESC
Dec. pos
SET and confirm with OK
CVM k 2
.
) again
Next
(f4). To exit without
