CVM k 2
Output range points
COMMUNICATIONS
Network protocol
Communication protocol
Speed (configurable)
Parity
Stop bits
ETHERNET OUTPUT
Network protocol
Communication protocol
Speed
ENVIRONMENT
Operating temperature
Storage temperature
Relative Humidity
Facility category
Degree of contamination
Protection index
MECHANICAL
Connection
STANDARDS
EmC
MODEL 405 ACCURACY
Currents
Neutral current
Voltages
Active Power P
Reactive Power Q
Apparent Power S
Frecuency
Active Energy
Reactive Energy
MODEL 402 ACCURACY
Currents
Neutral current
Voltages
Active Power P
Reactive Power Q
Apparent Power S
Frecuency
Active Energy
Reactive Energy
4.000
RS-485
modbus/RTU
9600, 19200, 38400, 57600 baud
even, odd or no parity
1 or 2
RJ-45 ETHERNET
modbus/TCP
10baseT / 100baseTx compatible
- 10...+ 40 °C
- 20... + 65ºC
95% with no condensation
CAT III in accordance with CEI 61010
2 in accordance with IEC 61010
IP51 front - IP20 rear
Terminal board with screws for rigid 2.5 mm (4.5 mm
flexible wires (AWg 11)
61000-4-2, 61000-4-3, 61000-4-11, 61000-4-4, 61000-4-5
Listed for industrial control equipment miscellaneous
device.
fILE: NmTR E227534
( % MEASURE ) ± ( DIGIT )
± 0,5% ± 1 from 10% to 120% of In
± 0,5% ± 1 from 10% to 120% of In
± 0,5% ± 1 from 20% to 120% of Un
± 0,5% ± 1 from 10% to 120% of In
± 0,5% from 10% to 120% of In
± 0,5% from 10% to 120% of In
± 0,01 Hz from 45 to 65 Hz
± 0,5%
± 0,5%
( % MEASURE ) ± ( DIGIT )
± 0,2% ± 2 from 10% to 120% of In
± 0,5% ± 1 from 10% to 120% of In
± 0,2% ± 2 from 20% to 120% of Un
± 0,2% ± 1 from 10 % to 120% of In
± 0,5% from 10% al 120% of In
± 0,5% from 10% al 120% of In
± 0,01 Hz from 45 to 65 Hz
± 0,2%
± 0,5%
) or
2
