EP812 Pentium
3.1 Microprocessors
The EP812 Series supports Intel® Celeron™ M and Pentium®
M CPUs. Systems based on these CPUs can be operated
under Windows 2000/XP and Linux environments. The system
performance depends on the microprocessor installed onboard.
Make sure all settings
microprocessor to prevent any damage to the CPU.
3.2 BIOS
System BIOS used on the EP812 Series is Phoenix-Award
Plug and Play BIOS. The EP812 Series contains a single 4Mbit
Flash.
3.3 System Memory
The EP812 Series industrial CPU card supports one 200-pin
DDR SODIMM socket for a maximum memory of 1GB DDR
SDRAMs. The memory module can come in sizes of 64MB,
128MB, 256MB, 512MB and 1GB.

Hardware Description

®
M All-in-One Capa Board User's Manual
C h a p t e r 3
Hardware Description
are correct for the installed
25
