POWER ON Function
This option allows users to select the type of power ON sequence
for the system to follow. The default value is "Button-Only".
BUTTON- Follows the conventional way of turning OFF system
power (via power button).
ONLY
Upon selecting this option, the KB POWER ON
Password line appears. Press <Enter> and you'll be
Password
prompted to enter and confirm a password of your
choice.
After setting the password, succeeding attempts to
power ON the system will result to null. For system to
activate, user must input the password via keyboard
then press <Enter>.
This option is very similar with that of Password. Hot-
Hot KEY
key combinations range from Ctrl-F1 to Ctrl-F12. User
may define this combination from the Hot key Power ON
option.
Onboard FDC Controller
Select Enabled if your system has a floppy disk controller (FDC)
installed on the system board and you wish to use it. If you install
and-in FDC or the system has no floppy drive, select Disabled in
this field. The options available are Enabled, Disabled.
Onboard Serial Port 1/Port 2
Select an address and corresponding interrupt for the first and
second serial ports. The options available are 3F8/IRQ4,
2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto.
UART2 Duplex Mode
The second serial port offers these infrared interface modes:
IrDA
ASKIR IrDA-compliant serial infrared port
Normal (default value)
NOTE:
The UART Mode Select will not appear on the
menu once you disable the setting of Onboard
Serial Port 2.
When UART Mode Select is set as ASKIR or IrDA, the options
RxD, TxD Active and IR Transmittion delay will appear.
