EP812 Pentium
Resources Controlled By
The Award Plug and Play BIOS can automatically configure all
the boot and Plug and Play-compatible devices. If you select Auto,
all the interrupt request (IRQ), DMA assignment, and Used DMA
fields disappear, as the BIOS automatically assigns them. The
default value is "Manual".
IRQ Resources
When resources are controlled manually, assign each system
interrupt as one of the following types, depending on the type of
device using the interrupt:
1. Legacy ISA Devices compliant with the original PC AT
bus specification, requiring a specific interrupt
(such as IRQ4 for serial port 1).
2. PCI/ISA PnP Devices compliant with the Plug and Play
standard, whether designed for PCI or ISA bus
architecture.
The default value is "PCI/ISA PnP".
DMA Resources
When resources are controlled manually, assign each system
DMA channel as one of the following types, depending on the
type of device using the interrupt:
Legacy ISA Devices compliant with the original PC
1.
AT bus specification, requiring a specific DMA
channel.
PCI/ISA PnP Devices compliant with the Plug and
2.
Play standard, whether designed for PCI or ISA bus
architecture.
The default value is "PCI/ISA PnP".
Memory Resources
This sub menu can let you control the memory resource.
Award BIOS Utility
®
M All-in-One Capa Board User's Manual
53
