43 N.C.
CN7: Hirose Connector for Inverter
PIN Description
12V
1
12V
2
5V
3
ENAB
4
GND
5
GND
6
7 GND

2.4.6 Flat Panel Bezel Connector: CN11

Power LED
This 2-pin connector, designated at Pins 1 and 3,5, connects
the system power LED indicator to its respective switch on the
case. Pin 1 is +, and pin 3,5 is assigned as -. The Power LED
lights up when the system is powered ON.
External Speaker and Internal Buzzer Connector
Pins 2, 4, and 8 of CN11 connect to the case-mounted
speaker unit or internal buzzer. Short
connecting the CPU card to an internal buzzer. When
connecting an external speaker, set these jumpers to Open
and install the speaker cable on pin 8 (+) and pin 2 (-).
ATX Power On/Off Button
This 2-pin connector, designated at Pins 9 & 10 of CN11,
connects the ATX power button of the front panel to the
EP812VEEA CPU card - allowing user to control the power
on/off state of the ATX power supply.
System Reset Switch
Pins 11 & 12 of CN11 connect to the case-mounted reset
switch and allow rebooting of your computer instead of turning
OFF the power switch. This is a preferred method of rebooting
in order to prolong the life of the system's power supply.
18
40 N.C.
pins 2-4 when
Hardware Description
