2.3.5 COM1~COM2 Mode: JP6, JP8

COM1(CN18)
Pin 1=5V
Short 1-3
Pin 1=12V
Short 3-5 or 5-7
* Pin 1=DCD Short 7-9
Pin 9=5V
Short 2-4
Pin 9=12V
Short 4-6 or 6-8
* Pin 9=RI Short 8-10
2.3.6 Audio Output Select Jumper: JP9
Options
Line Out
Speaker Out
2.3.7 Power Selection of Flat Panel 1'ST
Connector (VDDM1 of LVDS1): JP10
EP812 Series supports 3.3V or +5V flat panel displays.
Configure the jumper JP10 to the appropriate voltage of the flat
panel
VDDM1
3.3V
5V
12
JP6 COM2(CN13)
Pin 1=5V
Pin 1=12V
* Pin 1=DCD
Pin 8=5V
Pin 8=12V
* Pin 8=RI
Settings
Short 1-3, 2-4 (default)
Short 3-5, 4-6
Settings
Short 1-2(default)
Short 2-3
JP8
Short 1-3
Short 3-5 or 5-7
Short 7-9
Short 2-4
Short 4-6 or 6-8
Short 8-10
JP9
5 3 1
6 4 2
3
2 1
Hardware Description
