3.1

Microprocessors

The IMB541 series supports Intel
lake S), which enable your system to operate under Windows
system performance depends on the microprocessor. Make sure all correct settings are
arranged for your installed microprocessor to prevent the CPU from damages.
Caution: Make sure turnoff the power before you install the processor into
the CPU socket.
Note
3.2

BIOS

The IMB541 series uses AMI Plug and Play BIOS.
3.3

System Memory

The IMB541 supports four 288-pin DDR4 DIMM sockets for maximum memory capacity up to
128GB DDR4 SDRAMs. The memory module comes in sizes of 2GB, 4GB, 8GB, 16GB and
32GB.

Hardware Description

Hardware Description
Core™ i9 / i7/ i5/ i3/ Pentium®, Celeron® processors (Alder
®
IMB540 User's manual
Section 3
® 10 and Linux environments. The
