AXIOMTEK EP812 User Manual page 31

EP812 Pentium
CN21: Compact Flash Socket
CN21: Compact Flash Socket Pin Assignment
Pin Description
GND
1
2 Data 3
Data 4
3
Data 5
4
Data 6
5
Data 7
6
CS0#
7
8 Address 10
ATASEL
9
10 Address 9
Address 8
11
12 Address 7
VCC
13
14 Address 6
Address 5
15
16 Address 4
Address 3
17
18 Address 2
Address 1
19
20 Address 0
Data 0
21
22 Data 1
Data 2
23
24 IOCS16#
CD2#
25
Hardware Description
®
M All-in-One Capa Board User's Manual
Pin Description
CD1-
26
27 Data 11
Data 12
28
Data 13
29
Data 14
30
Data 15
31
CS1#
32
33 VS1#
IORD#
34
35 IOWR#
WE#
36
37 INTR
VCC
38
39 CSEL#
VS2#
40
41 RESET#
IORDY#
42
43 DMAREQ
DMAACK-
44
45 DASP#
PDIAG#
46
47 Data 8
Data 9
48
49 Data 10
GND
50
