EP812 Pentium M All-in-One Capa Board User's Manual
2.4

Connectors

The connectors allow the CPU card to connect with other parts
of the system. Some problems encountered by your system
may be a result from loose or improper connections. Ensure
that all connectors are in place and firmly attached. The
following table lists the function of each connector on the
EP812 Series. Their corresponding pin assignments are
described in Chapter 3.
Connectors
Power Connector
External USB Connector
DIO Connector
Mini PCI Connector
IDE Connector
LVDS Inverter Connector
LVDS Connector
Flat Panel Bezel Connector
Audio Connector
Com2 Connector
LPT port Connectors
1'ST Ethernet Connector
2'ST Ethernet Connector
USB Connector
Com1 Connector
Keyboard and Mouse Connector
Compact Flash Connector
DVI Connector
DDR SODIMM Socket (Reverse)
FAN Power connector
14
Label
CN1
CN2
CN3
CN4
CN5
CN7
CN9
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN21
CN23
DIMM1
FAN1
Hardware Description
