6.3.1.1.1 Save

Save Logo
Current
measurement
value
Entry number
Stress value at
time of entry
15
16
17
Save sub-menu keys
Send selected line to PC (See section 8)
Scroll page by page downwards
Scroll line by line downwards
Scroll line by line upwards
Scroll page by page upwards
Displays the time
Displays the date
Save number
Save
ESC
Return to standard display
Select an icon and enable the
available options
Select an icon and enable the
available options
Confirm selection
ESC
Return to previous display
Select an icon and enable the
available options
Select an icon and enable the
available options
Confirm selection
ESC
Return to previous display
Select an icon and enable the
available options
Select an icon and enable the
available options
19
Measurement PC transfer and alarm
indicators
Enregistrement de mesures :
Press to save:
The operation No.
The load value displayed
The time of save
or date of save
or No. of corresponding sensor.
If several sensors are shown, the total
is taken into consideration.
Save sub-menu:
Select the sub-menu.
See details and keys inthe following
table.
Confirm with
Confirmation screen:
In the event of total deletion,
confirmation is required.
Select one of the options
Confirm with
Choose between G "gros" or N "net" of the displayed
value
Graphic (disabled function)
Press to display one after another: The time, the
date or sensor identification
Delete selected line
Delete all (followed by confirmation screen)
Displays sensor identification
Radio reception
level
Type of data
Time, date or ID
Information at time
of save :
Time, date or ID
