2.2 Anchoring accessories

2.2.1 Chain anchoring accessories
To facilitate assembly and disassembly, Tractel offers a series of accessories for G 80 chain, equipped
with treated steel pins and DIN 6799 support collar type elastic rings.
The accessories are delivered boxed.
To implement this solution, it is essential that you use Tractel supplied pins and collars.
Using a pin with support collars.
Position the chain accessory on the sensor attachment ring and slide
the pin through the holes in the accessory and the sensor.
Lock off the pin with a collar.
For preference, use an assembly fork for the DIN 6799 collar.
2.2.1.1 Size in mm
C
D x E
L
L
B
A
d
G
H
M
M
D
L - L
E
0.5 < >3.2 t
5 - 6.3 t
0.5 < >3.2 t
5 - 6.3 t
l
I
J
M - M
I x J
WLL A B
111 88
185 150
10 t 210 155
WLL d l
13 50
20 76
10 t 24 92
WLL G
0.5 < >3.2 t 41
5 - 6.3 t 67
10 t 80
9
C D E
50 17 17
85 27 29
95 27 31
Support collar
10 mm DIN 6799
15 mm DIN 6799
19 mm DIN 6799
H I J
110 25 30
164 34 47
195 43 50
