Quick Start

Power
To power the unit, connect the included 9V DC power supply to the jack labeled DC 9V on the back
panel.
Warning: Using a non-Source Audio supply, especially an unregulated supply, could damage the unit.
Please be very cautious when using 3
Guitar/Audio Connections
Using standard ¼" mono cables, connect your guitar, bass, or other instrument to the I
and your amp (or the next audio device in the signal chain) to the O
When the power and audio connections have been made, the Aftershock is ready to play.
Brief Knob, Footswitch, and Button Descriptions
Drive Knob: Controls the amount of gain into the distortion circuit, which sets the amount of
distortion and sustain.
Level Knob: Controls the overall output level.
Clean Knob: Controls the amount of clean signal in the output.
Tone Knob: Controls the tone of the distortion.
Effect Switch: Selects between the three basic Distortion effect types – Tube, Heavy, and Fuzz.
Footswitch: Enables or bypasses the Distortion effect. The O
Distortion effect is engaged.
SA246
rd
-party power supplies.
Aftershock Bass Distortion User's Guide
1 jack.
UTPUT
/O LED will be lit green when the
N FF
1 jack
NPUT
3
