Aftershock Bass Distortion User's Guide
Welcome
Thank you for purchasing the Aftershock Bass Distortion. This powerful stereo effects pedal features
a collection of meticulously crafted Distortion sounds ranging from subtly driven sustain to highly
saturated distortion to thick fuzz and beyond. With a simple control set, the Aftershock can work in a
wide variety of musical settings, and the powerful MIDI and Neuro control options under the hood
provide access to a vast array of additional tonal possibilities.
The Aftershock is housed in a durable, lightweight aluminum housing, packing rack mount power and
flexibility into a compact, easy-to-use stompbox.
The USB and Neuro ports transform the Aftershock from a simple distortion pedal into a powerful
multi-effects unit. Using the free Neuro App (iOS / Android), a wide range of additional control
parameters and effect types (including a large collection of overdrive, fuzz, and distortion sounds)
are accessible. When used together with the Neuro Hub, the Aftershock is fully MIDI-controllable and
128 multi-pedal presets, or "scenes," can be saved for instant recall on the stage or in the studio. The
Aftershock can also connect directly to a passive expression pedal for expressive control of any
parameter.
The
Quick Start
guide will help you with the basics. For more in-depth information about the
Aftershock Bass Distortion, move on to the following sections, starting with Connections.
SA246
Aftershock Bass Distortion User's Guide
1
Advertisement
Table of Contents
Related Manuals for Source Audio Aftershock Bass Distortion
Summary of Contents for Source Audio Aftershock Bass Distortion
- Page 1 Aftershock Bass Distortion User’s Guide Welcome Thank you for purchasing the Aftershock Bass Distortion. This powerful stereo effects pedal features a collection of meticulously crafted Distortion sounds ranging from subtly driven sustain to highly saturated distortion to thick fuzz and beyond. With a simple control set, the Aftershock can work in a wide variety of musical settings, and the powerful MIDI and Neuro control options under the hood provide access to a vast array of additional tonal possibilities.
-
Page 2: Overview
Aftershock, easily recalled with a MIDI controller. You can also download any effects for the L.A. Lady Overdrive and Aftershock Bass Distortion and use them on the Aftershock Bass Distortion. Deep Control Set – Beyond the four knobs on the face of the Aftershock are many additional parameters. -
Page 3: Quick Start
To power the unit, connect the included 9V DC power supply to the jack labeled DC 9V on the back panel. Warning: Using a non-Source Audio supply, especially an unregulated supply, could damage the unit. Please be very cautious when using 3 -party power supplies. - Page 4 External Control ............................. 19 Neuro App .............................. 22 Specifications ............................32 Troubleshooting ............................. 32 Frequently Asked Questions ........................33 Rubber Feet ............................35 Waste Disposal Notes ..........................35 Warranty ..............................35 Version History ............................37 SA246 Aftershock Bass Distortion User’s Guide...
-
Page 5: Connections
Neuro App data will be on the ring contact. Input 2 only accepts data from the Neuro App. Data from the Neuro Hub comes from the Control Input port. SA246 Aftershock Bass Distortion User’s Guide... - Page 6 The ring contact on Output 2 acts as a data connection for the Neuro App, passing data from the Aftershock to the next Source Audio effect in your signal chain. You can daisy-chain the Neuro App data regardless of whether Output 2 is configured to output audio or not. Connect Output 2 to the next device’s Neuro App Data input (usually Input 2) using a stereo (TRS) ¼”...
- Page 7 The 3.5 mm Control Input port connects to external control devices such as the Dual Expression Pedal, Reflex Universal Expression Pedal, Neuro Hub, and Hot Hand Motion Controller. For more information, refer to the Expression Pedal Input, Hot Hand Input, and Neuro Hub sections of the User’s Guide. SA246 Aftershock Bass Distortion User’s Guide...
-
Page 8: Basic Distortion Operation
Overshoot: Depending on the characteristics of diodes and transistors in the circuit, the signal may exceed its normal clipping point before settling, which is known as overshoot. SA246 Aftershock Bass Distortion User’s Guide... -
Page 9: Effect Types
(iOS / Android) or the built-in USB port (Mac / Windows). The Aftershock Bass Distortion is compatible with Source Audio’s Overdrive and Fuzz effects, so it is possible to load Overdrive, Distortion, and Fuzz effects on the Aftershock at the same time. -
Page 10: Controls
EVEL compression. Clean Knob The Clean Knob adjusts the amount of dry signal on the output. This is very useful for keeping a solid low end with high amounts of drive. SA246 Aftershock Bass Distortion User’s Guide... -
Page 11: Preset Storage And Recall
LED blinks rapidly 3 times. NGAGE YPASS Now you can engage and bypass the Aftershock using the O , and each time OOTSWITCH you engage the effect, your saved preset will be recalled. SA246 Aftershock Bass Distortion User’s Guide... -
Page 12: Stacking And Parallel Processing "Inside The Box
Stacking overdrive, fuzz, and distortion pedals is a common method for creating unique textures that would not be possible with a single pedal. This normally involves putting two pedals in series, one after the other, to create multiple gain stages. Typically, this requires two separate distortion pedals, SA246 Aftershock Bass Distortion User’s Guide... -
Page 13: Stereo Routing
It can act as a stereo splitter, merger, or true stereo effect, and it can also be set up in a number of other unique signal routing modes. By default, SA246 Aftershock Bass Distortion User’s Guide... - Page 14 2 goes to distortion circuit B. The outputs NPUT NPUT of circuits A and B are mixed and sent to O 1. This is useful for mixing a stereo source down to a UTPUT mono output. SA246 Aftershock Bass Distortion User’s Guide...
- Page 15 From Guitar To Amp (L) To Amp (R) External Loop Pre-Effect: The external loop options allow an external effect (whether a Source Audio product or a third-party product) to be connected to the Aftershock’s I 2 and O 2. When the...
-
Page 16: Parametric Eq
Q, Band 3 is a peaking filter at 3 kHz with a 1.5 dB boost and relatively low Q, and Band 4 is a high shelf filter at 10 kHz with a 2.5 dB cut. SA246 Aftershock Bass Distortion User’s Guide... -
Page 17: Low Cut Filter
(around 10 Hz to 30 Hz) to reduce speaker excursion and improve the clarity of the bass. Guitarists often use low cut filters set somewhat higher (around 80 Hz) in order to give the bass player additional room in the low end of the mix. SA246 Aftershock Bass Distortion User’s Guide... -
Page 18: Loretain
EQ is disabled (flat), and the Low Cut filter is set to 10 Hz. LoRetain LoRetain is a technique used by Source Audio to maintain a solid low end even with high amounts of distortion. This is particularly useful for bass players or extended-scale guitar players (7-string and 8- string guitars) that need to maintain a strong fundamental while keeping high drive on the upper frequencies. -
Page 19: External Control
ONTROL NPUT In the case of an expression pedal with a TRRS plug, like Source Audio’s expression pedals, the tip connection is power, the first ring is the X axis expression signal, the second ring is the Y axis expression signal, and the sleeve connection is ground. - Page 20 An external switch can also work as a sort of expression pedal that only has two positions: on and off. The external switch can be either momentary or latching. To use this mode, connect an external switch to C . The following plug configuration is ONTROL NPUT required: SA246 Aftershock Bass Distortion User’s Guide...
- Page 21 Ground Power Y Exp X Exp Configuring the Hot Hand When the Hot Hand is connected to the Aftershock, follow these simple steps to calibrate it and map it to control different effect parameters. SA246 Aftershock Bass Distortion User’s Guide...
-
Page 22: Neuro App
Make sure the headphone volume on your mobile device is set to maximum when using the Neuro App for the most reliable device to pedal communication. SA246 Aftershock Bass Distortion User’s Guide... -
Page 23: Main Menu
These sounds can be burned into the internal preset memory (three sounds corresponding to the three positions of the effect selector switch, and an additional preset accessible via the footswitch), saved to a preset file in the app, emailed to friends, posted to the Neuro Community site, and more. SA246 Aftershock Bass Distortion User’s Guide... - Page 24 If you wish to update all of the parameters on the hardware so that they match what is shown on the Sound Editor screen, tap the Send All button. This sends every parameter setting over to the hardware and guarantees that its settings will exactly match what is shown in the app. SA246 Aftershock Bass Distortion User’s Guide...
- Page 25 Create New Sound Closes the current sound being edited and opens a new sound for editing with default settings. Browse Sounds Returns to the Browse Sounds screen, which displays a list of user and web presets. SA246 Aftershock Bass Distortion User’s Guide...
- Page 26 To do this, follow these steps: Load the sound in the Sound Editor. Hit the Send All button. Hit the Burn button. Select one of the Effect Selector Switch positions to overwrite it. SA246 Aftershock Bass Distortion User’s Guide...
- Page 27 User: Presets that you have created and saved. Factory: Presets that were created by Source Audio. New presets will automatically be added to this list as Source Audio creates them. Published: Presets that you have created and uploaded to the Neuro Community for other users.
- Page 28 Enable External Tap Tempo Switch Allows the Source Audio tap tempo switch to be connected to the Control Input Port. This allows the tempo for the LFO to be tapped in directly. The Control LED will blink in time with the tempo if this mode is enabled.
- Page 29 In the case of a purely mono audio signal path, the Neuro data can be input to the first effect directly from the mobile device and then carried on to the second effect via TRS cable. Source Audio makes couplers that are designed specifically for connecting multiple One Series products in series. These couplers are available on the Source Audio Online Store.
- Page 30 One Series families to create a single, stage-ready system. It features shared MIDI, passive expression pedal input, Hot Hand connectivity, and USB, and can connect to up to five Source Audio pedals. The Neuro Hub features a powerful scene saving functionality, which allows you to create up to 128 multi-pedal presets known as scenes, each recallable via MIDI program change messages.
- Page 31 Since the Aftershock has no time-dependent parameters, it will ignore MIDI clock. The Aftershock’s USB port is plug-and-play ready for Windows and Mac computers. The Aftershock uses class-compliant drivers, so no special drivers are needed. Just power up the Aftershock and SA246 Aftershock Bass Distortion User’s Guide...
-
Page 32: Specifications
USB cable. The computer should automatically recognize the Aftershock, which will be identified as “Source Audio One Series” in the operating system. USB connectivity brings many benefits, such as the ability to download firmware updates to the Aftershock, configuration of advanced parameters, accessing new effect types created by the Source Audio engineers, and MIDI connectivity to audio production software running on the computer. -
Page 33: Frequently Asked Questions
What kind of instruments can I connect to the Aftershock’s inputs? The Aftershock’s audio inputs are high impedance (~ 1 MΩ) and they can accept high impedance signal sources like guitars/basses with passive pickups, as well as low impedance sources like line- SA246 Aftershock Bass Distortion User’s Guide... - Page 34 MIDI continuous controller to the Effect Type switch. Then, send a CC message with one of the following values to enable a certain effect type: CC Value Effect Type Tube Drive Smooth Tube Power Stage Crunch Tube TS9000 Big Pi SA246 Aftershock Bass Distortion User’s Guide...
-
Page 35: Rubber Feet
Source Audio, LLC (hereinafter “Source Audio”) warrants that your new Source Audio One Series Aftershock Bass Distortion, when purchased at an authorized Source Audio dealer in the United States of America (“USA”), shall be free from defects in materials and workmanship under normal SA246 Aftershock Bass Distortion User’s Guide... - Page 36 Source Audio. Warranty Information Source Audio may, at its option, require proof of the original purchase date in the form of a dated copy of the original authorized dealer’s invoice or sales receipt. Service and repairs of Source Audio products are to be performed only at the Source Audio factory or a Source Audio authorized service center.
-
Page 37: Version History
This Limited Warranty only applies to products sold and used in the USA. Source Audio shall not be liable for damages or loss resulting from the negligent or intentional acts of the shipper or its contracted affiliates. You should contact the shipper for proper claims procedures in the event of damage or loss resulting from shipment.
