Parametric Equalizer
+6
0 1 2
4
3
-6
50 100 200 300 500 1.0k 2.0k 3.0k 5.0k 10.0k 20.0k
By default, Band 1 is a shelf when it is boosted (gain > 0 dB) and a high pass when it is cut (gain < 0
dB). By default, Band 4 is a shelf when it is boosted (gain > 0 dB) and a low pass when it is cut (gain <
0 dB). Using the Neuro App, Bands 1 and 4 can optionally be configured as a shelves when cutting
(gain < 0 dB), with optional values for slope and rolloff.
The left channel and right channel can each have unique boost/cut values for each of the 4 bands.
However, the filter types and cutoff frequencies (or center frequencies) must be the same for both
channels.
The physical T K directly controls the boost or cut of the parametric EQ's bass and treble
ONE NOB
bands.

Low Cut Filter

The Aftershock also includes two low cut filters (a.k.a. high pass filter) with an adjustable frequency.
This filter is very useful for cutting out low frequencies that do not contribute to the sound of the
instrument, as well as subsonic frequencies which cannot be heard at all. Bass players often use low
cut filters set very low (around 10 Hz to 30 Hz) to reduce speaker excursion and improve the clarity of
the bass. Guitarists often use low cut filters set somewhat higher (around 80 Hz) in order to give the
bass player additional room in the low end of the mix.
SA246 Aftershock Bass Distortion User's Guide 17
