Controls

Drive Knob
Effect Switch
Clean Knob
Engage/Bypass
LED
Knobs
Drive Knob
The D K adjusts the amount of gain applied to the signal. Dial down the drive for a cleaner,
RIVE NOB
more articulate tone or crank it up for over-the-top doses of distortion.
Level Knob
Adjusts the output level of the effect. This is useful for setting the level of the distortion effect
compared to the bypassed signal. Note that because the distortion effect compresses the signal in
the clipping/saturation stage, the dynamic range of the distorted signal will be less than the dry
signal, and the L
EVEL
compression.
Clean Knob
The Clean Knob adjusts the amount of dry signal on the output. This is very useful for keeping a solid
low end with high amounts of drive.
SA246
Control LED
K can be used to compensate for the loss of level that results from this
NOB
Aftershock Bass Distortion User's Guide
Control Input Button
Level Knob
Tone Knob
Engage/Bypass
Footswitch
