Mono, Dry Thru: I 1 goes to distortion circuit A and out to O
NPUT
to O 2. This is useful especially for bass guitars, where having a dry output is useful in maintaining a
UTPUT
solid low end (this can also be achieved using the Aftershock's mix control or LoRetain feature, which
are accessible via the Neuro app and MIDI).
External Loop Pre-Effect: The external loop options allow an external effect (whether a Source Audio
product or a third-party product) to be connected to the Aftershock's I
Aftershock is bypassed, the external effect will be out of the circuit. When the Aftershock is enabled, the
external effect will be put in series with the Aftershock's distortion circuit. O
the external effect's input, and the external effect's output should connect to I
In Pre-Effect mode, the guitar signal will go to the external effect first, and then the Aftershock's
distortion circuit second.
In Post-Effect mode, the guitar signal will go to the Aftershock's distortion circuit first, and then to the
external effect second.
