Start of Packet

Target Address
>
ASCII code 62
(1 character)
EXAMPLE: >0412/MUT=1{CR}{LF}
5.3.4.1 Start of Packet
The '<' and '>' characters indicate the start of packet. They may not appear anywhere else within the body of the message.
•
Controller to Target: This is the character '<' (ASCII code 60)
•
Target to Controller: This is the character '>' (ASCII code 62)
5.3.4.2 Target Address
Up to 9,999 devices can be uniquely addressed. In both EIA-232 and EIA-485 applications, the permissible range of values is 1 to 9999. It
is programmed into a target unit using the remote control port.
The controller sends a packet with the address of a target - the destination of the packet. When the target responds,
the address used is the same address, to indicate to the controller the source of the packet. The controller does not
have its own address.
5.3.4.3 Address Delimiter
This is the 'forward slash' character ' / ' (ASCII code 47).
Serial-based Remote Product Management
Address Delimiter
/
ASCII code 47
(4 characters) (1 character)
TRP1000-4450 Troposcatter C-Band Outdoor Amplifier
Target-to-Controller
Instruction Code Code Qualifier
=, ?, !, or *
ASCII codes
61, 63, 33, or 42
(3 characters) (1 character)
5–5
Revision 0
Optional Arguments End of Packet
Carriage Return, Line
Feed
ASCII codes 13,10
(2 characters)
(From 0 thru n
characters)
MN-TRP1000-OD
