3.2

Getting Started: Prepare for the Firmware Download

1. Identify the firmware number and its version number.
User-supplied items needed:
•
A Microsoft Windows-based PC, equipped with available serial and Ethernet ports; a
compatible Web browser (e.g., Internet Explorer); and a terminal emulator program (e.g.,
Tera Term or HyperTerminal).
•
An M&C adapter cable for connection between the unit's 'J6 | COMM 1' port and the user
PC using a 19-pin to 9-pin Serial Adapter Cable, or a 19-pin to RJ-45 Ethernet Adapter
Cable.
a. Connect the Adapter Cable from the unit's 'J6 | COMM 1' port to the pertinent
b. On the PC – configure the terminal emulator program.
•
•
•
c. Energize the TRP1000-4450.
d. Obtain the firmware information via one of the following methods:
Updating Firmware
port on the user PC.
Refer to your terminal emulator program HELP feature or user
guide for operating and configuration instructions.
19200 bps (Baud
Rate)
Parity = NO
Local Echo = ON
•
Using Serial Remote Control or Telnet via the user PC terminal
emulation program – Log in to the TRP1000-4450, and then use
'FRW' remote query to obtain, and make note of, the firmware information:
Type (without the quotes) "<1/FRW?"<cr> at the command prompt to query
the TRP1000-4450 for its Firmware Number.
See Chapter 5. SERIAL-BASED REMOTE PRODUCT
MANAGEMENT for information and instructions on using
Remote Commands and Queries.
TRP1000-4450 Troposcatter C-Band Outdoor Amplifier
•
8 Data Bits
•
Port Flow Control =
NONE
3–2
Revision 0
•
1 Stop Bit
•
Display New line
Rx/Tx: CR
MN-TRP1000-OD
