4.3

Simple Network Management Protocol (SNMP) Interface

The SNMP is an Internet-standard protocol for managing devices on IP networks. The SNMP-
managed network consists of three key components:
•
The managed device. This includes the TRP1000-4450.
•
The SNMP Agent. This is the software that runs on the TRP1000-4450. The TRP1000-
4450 SNMP Agent supports both SNMPv1 and SNMPv2c.
•
The user-supplied NMS. This is the software that runs on the manager.
4.3.1 Management Information Base (MIB) Files
MIB files are used for SNMP remote management of a unique device. A MIB file consists of a tree
of nodes called Object Identifiers (OIDs). Each OID provides remote management of a particular
function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP Network
Monitoring System server. The following MIB files are associated with the TRP1000-4450:
MIB File/Name
(where 'x' is revision letter)
FW-0021006x.mib
ComtechEFData Root MIB file
TRP1000-4450 MIB file
FW-0021007x.mib
TRP1000-4450 Traps MIB file
Ethernet-based Remote Product Management
TRP1000-4450 Troposcatter C-Band Outdoor Amplifier
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products
and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247.95
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the amplifier functions
Trap MIB file is provided for SNMPv1 traps common for TRP1000-4450.
