2.4
Power On the Unit
Never turn the unit ON without proper output termination on the 'J2 | RF OUT' port.
Individuals can be exposed to dangerously high electromagnetic levels.
The TRP1000-4450 does not contain a 'Power On/Off' switch. The SSPA is powered ON by
connecting the 'J3 | AC IN' power connector to the appropriate prime power source. The Mute or
Transmit status of the SSPA will automatically come up in the factory default state (factory default
= transmit off, not muted).
System Connections, Installation and Startup
TRP1000-4450 Troposcatter C-Band Outdoor Amplifier
2–8
Revision 0
MN-TRP1000-OD
