ASCII Symbol Descriptions

Abbreviation
NUL
SOH
STX
ETX
EOT
ENQ
ACK
BEL
BS
HT
LF
VT
FF
CR
SO
SI
Table 13.6.A lists all possible ASCII symbols displayed on the Port Transmit and Port Receive pages. (For more
information about Port Transmit and Port Receive, see Section 12.5.7, "Port Transmit and Port Receive."
Some notes on the ASCII port display:
·
Printable ASCII characters will appear as ASCII.
Non-printable ASCII characters will appear as labels surrounded by { } brackets (for example, {NUL}).
·
Non-ASCII characters will appear as hexadecimal surrounded by [ ] brackets (e.g. [IF]).
·
A received BREAK will appear as <BRK>.
·
Description
Null
Start of Heading
Start of Text
End of Text
End of Transmission
Enquiry
Acknowledge
Bell
Backspace
Horizontal Tabulation
Line Feed
Vertical Tabulation
Form Feed
Carriage Return
Shift Out
Shift In
Table 13.6.A. ASCII symbols
Abbreviation
DLE Data Link Escape
DC Device Control
NAK Negative Acknowledge
SYN Synchronous Idle
ETB End of Transmission Block
CAN
EM End of Medium
SUB
ESC
FS File Separator
GS Group Separator
RS Record Separator
US Unit Separator
SP Space (blank)
DEL
BRK Break Received
Description
Cancel
Substitute
Escape
Delete
