DPS Telecom NetGuardian-16S User Manual page 32

26
Fig. 13.2. Configure the Ethernet port parameters
1. Once a connection is established, the NetGuardian-16S will respond with "Password."
2. Type the default password, "dpstelecom," then press Enter.
Note: DPS strongly recommends changing the default password.
3. The NetGuardian-16S's main menu will appear.
4. Type C for the C)onfig menu.
5. Type E for E)dit menu.
6. Type E for port settings.
7. Type R for Private settings, or type U for Public settings.
8. Configure the unit address, subnet mask, and default gateway.
9. ESC to the main menu.
10. When asked if you would like to save changes, type Y (yes).
11. Reboot to save the new configuration to the NetGuardian-16S.
12. Now you can connect to the NetGuardian-16S via LAN and complete the configuration.
