8.2

LCD Command Menu

Fig. 8.2.1. LCD display, showing the Standard Prompt
The LCD Command Menu provides commands for controlling some of the NetGuardian-16S's basic functions:
temporarily silencing the alarm speaker, rebooting the unit, and running the TTY configuration utility.
When no Command Menu item is selected and no alarms or relays are active, the LCD displays the firmware
version and the Standard Prompt, Press MENU for front panel options. (See Figure 8.2.1,
above.)
To access the Command Menu, press the Menu button.

8.2.1 Sound off

Fig. 8.2.1.1. Sound Off command
Sound off
The Sound off command suppresses sounds from the alarm speaker for a user-defined period of 10, 20, or 30
minutes. (Note: The Sound off command setting does not silence audible alarms from the integrated Building
Status Unit. For details on the integrated BSU, see Section 6, "Building Status Unit.")
To scroll to the next menu command, press the – button.
To change the Sound off setting, press Sel to select the command. The arrow cursor (>) will move to the right
of the colon (:) in Sound off: to indicate that the command submenu is selected. Press the Ack/+ and –
buttons to scroll through the Sound off time period options. Select 0 minutes to allow all sounds. When the time
period you want is displayed, press Sel to make your selection.
To exit the Command Menu without changing the Sound off setting, press Menu.
