14.5.4 System Alarms

Fig. 14.5.4.1. System Alarms summary
Clicking the System Alarms link in the Monitor menu opens the System Alarms page (see Figure 12.5.4.1,
above). This page shows the Alarm or Clear status of each of the NetGuardian-16S's 26 internal housekeeping
alarms. You'll probably have to scroll down the page to view all 26 system alarms.
For a full description of the NetGuardian-16S's system alarms, see Section 13.5, "System Alarm Descriptions," in
the Reference section.
The System Alarms page lists each system alarm by its point number and alarm description. The State column
will display "Clear" in GREEN if the alarm is inactive and "Alarm" in RED if the alarm is active.
