NetGuardian-16S Trap OIDs

The illustration and tables below outline the SNMP OIDs for NetGuardian-16S alarm points. This illustration
begins with dpsRTU; however, the MIB object identifier tree has several levels above that. The full English
name is as follows: root.iso.org.dod.internet.private.enterprises.dps-Inc.dpsAlarmControl.dpsRTU. Therefore,
dpsRTU's full object identifier is 1.3.6.1.4.1.2682.1.2. Each level beyond dpsRTU adds another object
identifying number. For example, the object identifier of the Display portion of the Control Grid is
1.3.6.1.4.1.2682.1.2.3.3 because the object identifier of dpsRTU is 1.3.6.1.4.1.2682.1.2 + the Control Grid (.3) +
the Display (.3).
_OV_vTraps Ident
(.0)
(O.)_OV_Traps points
_OV_vTraps
(1.3.6.1.4.1.2682.1.2.0)
PointSet (.20)
PointClr (.21)
SumPSet (.101)
SumPClr (.102)
ComFailed (.103)
ComRestored (.014)
P0001Clr (.20001) through
P0064Set (.10064)
P0001Clr (.20001) through
P0064Clr (.20064)
(.3) ControlGrid points
ControlGrid
(1.3.6.1.4.1.2682.1.2.3)
Port (.1)
Address (.2)
Display (.3)
Point (.4)
Action (.5)
1.3.6.1.4.1.2682.1.2
DisplayGrid
(.1) (.2)
DisplayEntry (.1)
See Table 13.1.A
(.1) Identity points
(1.3.6.1.4.1.2682.1.2.1)
Manufacturer (.1)
Firmware Version (.3)
DateTime (.4)
ResyncReq (.5)*
* Must be set to "1" to perform the resync
request which will resend TRAPs for any
standing alarm.
(.4) NVRamSection points
NVRamSection (1.3.6.1.4.2682.1.2.4.1)
NVsNmbr (.1)
NvsStatus (.3)
dpsRTU
ControlGrid
(.3)
NVRamSection (.1) AlarmEntry (.1)
Ident
Model (.2)
NvsData (.2)
NVRamGrid AlarmGrid
(.4)
(.2) DisplayGrid points
DisplayEntry
(1.3.6.1.4.1.2682.1.2.2.1)
Port (.1)
Address (.2)
Display (.3)
DispDesc (.4)*
PntMap (.5)*
(.5) AlarmEntry points
AlarmEntry
(1.3.6.4.1.2682.1.2.5.1)
Aport (.1)
AAddress (.2)
ADisplay (.3)
APoint (.4)
APntDesc (.5)*
AState (.6)
* For specific alarm points, see
Table 13.1.A.
(.5)
