13.3.5.1 Reloading NetGuardian Configuration Data

1. From the Start menu on your PC, select RUN.
2. Type "ftp" followed by the IP address of the NetGuardian-16S you are backing up (e.g. ftp
126.10.120.199).
3. After the connection is made press Enter.
4. Enter the password of the NetGuardian-16S (default password is dpstelecom), then press ENTER.
5. Type "binary" and press Enter (necessary for NetGuardian-16S file transfer).
6. Type "lcd" and press Enter (this allows you to change the directory of your local machine).
7. Type "put" followed by the name you defined for the NetGuardian-16S backup file and press Enter (e.g.
put ngdbkup.ngd).
8. Type "literal REBT" to reboot the NetGuardian-16S.
9. After reloading, type "bye" and press Enter to exit.
