5 USER INTERFACE; MONITORING AND DATA
TRANSMISSION
5.1

User interface mode

Normally, the AURORA inverter operates automatically, and does not require any
particular controls. When solar radiation is sufficient to generate power to be input
into the grid (for example, at night), AURORA automatically disconnects itself,
entering into stand-by mode.
The operating cycle is automatically resumed when solar radiation becomes
sufficient. This will be indicated by the LEDs.
The AURORA inverter is capable of supplying operational information through the
following instruments:
Indicator lights (luminous LEDs)
Operational data shown on the LCD display
Data transmission on a dedicated serial RS-485 line. Data can be collected
from a PC or data logger, equipped with an RS-485 port. If an RS-485 line is
used, it may be beneficial to use the RS485-USB converter, model number
PVI-USB-RS485_232. Furthermore, an optional AURORA Easy Control data
logger can be used.
WARNING: the RS-485 cable must ensure a protection of at least 600V.
