Use and installation manual
(PVI-10.0/12.0-I-OUTD(-S)-400 Rev:1.3)
Vin1: input instant voltage value measured at channel 1 input
Iin1 : input instant current value measured at channel 1 input
Vin2: input instant voltage value measured at channel 2 input
Iin2 : input instant current value measured at channel 2 input
Or:
In a configuration with only one input connected, and a second input in parallel,
this screen is shown instead of the 2 screens previously described.
Pin1: measured input instant power of channel 1
Pin2: measured input instant power of channel 2
In a configuration with only one input connected, and a second input in parallel,
this screen is shown instead of the screen previously described
IsoQF: value indicates the quality of ground insulation with reference to the unit
value; the unit value is the value sufficient for operation.
In the example above, insulation is 5.5 times greater than the minimum.
Vgns: measured voltage value at the negative ground input.
This screen is only shown in the case of positive or negative terminal grounding of
the terminal.
Vin1 0 V
I in1 0.0 A
Vin2 0 V
I in2 0.0 A
Vin 0 V
I in 0.0 A
Pin 1 0 W
Pin 2 0 W
Pin 0 W
Iso QF 5.5
Vgnd 200V
