Brand: POWERONE
Type: Solar On Grid String Inverter
Models: 10kW-SGTU-103, 12.5kW-SGTU-1253, 15kW-SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, POM
SGTU 30kW, SGTU-333N, POM SGTU 50kW
DOCUMENT DETAILS
Following Document Explains Connections of TrackSo Logger with PowerOne Inverters for Following Type
1) 10kW-SGTU-103, 12.5kW-SGTU-1253, 15kW-SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, SGTU-333N
a. Type A- with RS485 Output
b. Type B- with RS232 Output
2) POM SGTU 30kW, POM SGTU 50kW, POM SGTU 60kW (RS485)
Before Proceeding further kindly identify the Inverter type you are
connecting with the Datalogger and accordingly proceed with the instruction
For a Modbus-RTU-RS232 type Inverter you will require logger with RS232 Communication port.
For a Modbus-RTU-RS485 type inverter you will require logger with RS485 Communication port.
TRACKSO INSTALLATION GUIDE FOR POWER ONE INVERTERS
mentioned for that model
Note:
Advertisement
Table of Contents
Related Manuals for Power One 10kW-SGTU-103
Summary of Contents for Power One 10kW-SGTU-103
- Page 1 TRACKSO INSTALLATION GUIDE FOR POWER ONE INVERTERS Brand: POWERONE Type: Solar On Grid String Inverter Models: 10kW-SGTU-103, 12.5kW-SGTU-1253, 15kW-SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, POM SGTU 30kW, SGTU-333N, POM SGTU 50kW DOCUMENT DETAILS Following Document Explains Connections of TrackSo Logger with PowerOne Inverters for Following Type 1) 10kW-SGTU-103, 12.5kW-SGTU-1253, 15kW-SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, SGTU-333N...
-
Page 2: Setting The Baud Rate
1-A - The communication terminals (RS485) are located at the bottom of the inverter. And there are two connection terminals on the configuration circuit board: +- terminal blocks. Connection steps Valid for 10kW-SGTU-103, 12.5kW- • Please unscrew the RS485 terminal SGTU-1253, 15kW-SGTU-153, 17kW- SGTU-173, 20kW-SGTU-203, SGTU- •... - Page 3 1-B CONNECTION DIAGRAM 1-B - The communication terminals (RS232) are Valid for 10kW-SGTU-103, 12.5kW-SGTU-1253, 15kW- located at the bottom of the inverter. SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, SGTU-333N With Modbus-RTU-RS232 Output FigureI PT1-A – Powerone RS232 Output Communication Board Connection Steps: PowerOne DB9 TrackSo Pin No.
- Page 4 Valid for 10kW-SGTU-103, 12.5kW-SGTU- DEFAULT CONFIGURATION IN TRACKSO IOT GATEWAY 1253, 15kW-SGTU-153, 17kW-SGTU-173, 20kW-SGTU-203, SGTU-333N Inverter ID: 1, 2, 3, 4 ….(Set as perData Logger) Baud Rate: 9600 (Default) (Values: 9600, 19200, 38400) With Modbus-RTU-RS232 Output Data Bits: 8 , Stop Bit: 1 , Parity: None...
- Page 5 SETTING THE DATE & TIME Valid for 10kW-SGTU-103, 12.5kW-SGTU- For a precise calculation of the statistics in the inverter itself and in a 1253, 15kW-SGTU-153, 17kW-SGTU-173, monitoring system, date and time have to be correct. 20kW-SGTU-203, SGTU-333N With Modbus-RTU-RS232 Output Menu >>...
-
Page 6: Connection Diagram
Valid for POM SGTU 30kW, POM SGTU 50kW, POM SGTU 60kW 2 CONNECTION DIAGRAM With Modbus-RTU-RS485 Output The communication terminals (RS485) are located at the bottom of the inverter. And there are two connection terminals on the configuration circuit board: ++ - - terminal blocks. Figure P2:A–... - Page 7 Valid for POM SGTU 30kW, POM SGTU 50kW, POM SGTU 60kW Multiple Inverters With Modbus-RTU-RS485 Output Pin 2 & 4 of Inv-1 is connected to Pin 1 & 3 of next inverter in Daisy Chain. When two or more inverters are in parallel communication, 2P DIP switch beside RS485 of the last one should be “ON”. Or else, it may cause communication interruption.
-
Page 8: Set Communication Protocol
SETTING THE INVERTER ID Valid for POM SGTU 30kW, POM SGTU 50kW, POM SGTU 60kW The inverter ID is used to identify the inverter in a RS485 connection With Modbus-RTU-RS485 Output • Set a different inverter ID for each inverter in the PV plant. Otherwise, the inverters cannot be correctly identified. - Page 9 TRACKSO WORKING 1. Insure correct connections as detailed in the installation guide. 2. Insert the SIM card. 3. Switch on the power to the TrackSo device. (Minimum 12V/1A input is required) 4. Power LED (Red) of TrackSo IoT gateway glows and stays ON. NOTE: TrackSo IoT Gateway will only be able to send data if the GPRS network is available at the installed location.
- Page 10 5. To check the exact network status send the following message to mobile number of the device SMS Command= *2222#<Stat.gsm> IMEI IMEI No. of the data logger (Device Key) Network SIGN Signal Strength out of 31 GPRS CONT- connected , NC- not connected Connected to TrackSo Server or not CONT- connected, NC- not connected no.
- Page 11 9. If the state remains Not receiveing for more than 10 minutes, click on your email ID at the top right of the screen and click on ‘Event Ingestion Logs’ in the dropdown. 10. Check if there is some log generated at the time of installation of the TrackSo IoT Gateway device. If NO, please restart the device and try the same flow again.
