Type 1 - Without T-Harness - Directed DS4+ Installation Manual

Type 1 - without T-Harness

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 10 for important information on this installation.
Start/Stop Unit
(White conn. at steering column)
(+) Ign. 2 Interrupt: Gray/Red, pin 3 Cut
16 15 14 13 12 11 10 9 8 7 6 5 4 3
32 31 30 29 28 27 26 25 24 23 22 21 20 19
(-) PTS: Green/White
or Lt.Green/Red, pin 20
87
86 85
86 87 85
87a
87a
(+)12V
30
30
Optional
HS CAN Low: Red/Yellow, pin 8
HS CAN High: White/Black, pin 7
(+) Ignition:
Lt. Green/Red,
pin 10
10 7
12 11 9 8 6 5 4 3 2 1
24 23 22 21 20 19 18 17 16 15 14 13
(+) Starter: Start/Stop Unit
(White conn. at
Brown/Black,
steering column)
pin 23
(+) Trunk Release Actuator: Green, pin 2
1 2 3 4 5 6 7 8 9 10
1112 13 14 15 16 17 18
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
9
(-) Trunk Release:
2 1
Trunk Release Switch
18 17 (White conn. in driver dash)
(+) Ign. 3 Interrupt:
Cut
Violet, pin 17
Siren
(+) Accessory 1: Yellow/Green, pin 2
(+) Accessory 2: Brown/Red, pin 14
(-) Parking Lights: Parking Lights Interrupt:
Yellow, pin 3 Green, pin 4
1 2 3 4 5 6
Parking Light
Switch Assembly
White/Blue,
pin 3
1 2 3
(MUX) Door Lock Output: Violet/Brown: 6
(-) Parking Lights Output: Lt.Green/Black: 1
(-) Trunk Release Output: Red/White: 4
(+) Accessory 2 Output: Violet/Black: 8
(-) Ignition Interrupt Output: Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Trunk Shunt Input: Orange/Black: 18
Hood Pin
Parking Light Interrupt (vehicle side): Blue/White: 1
Parking Light Interrupt (conn. side): Blue: 3
(+) 12V:
White, pin 1
Cut
1
Fuse Box
(White conn.
at drivers kick)
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(+) Accessory 1 Output: White: 7
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) Starter Output: White: 5 & 11
(+) 12V: Red: 6 & 12
(+) Ignition Output: Lt.Green/Red: 7
(+) 12V: Lt. Green: 8
(-) Ground: Black: 10
It is important to check that the
fuses are positioned correctly. See
Fuse selection on the next page for
more information.
DS4
DS4+
DS4+ MA3
