Type 4 - without T-Harness

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 19 for important information on this installation.
HS CAN Low: Red, pin 8
HS CAN High: Green, pin 7
(+) Ignition:
Yellow,
pin 10
12 11 10 9 8 7 6 5
24 23 22 21 20 19 18 17
(+) Starter:
Gray, pin 23
Start/Stop Unit
(White conn. at steering column)
(+) Ign. 2 Interrupt: Pink, pin 3
16 15 14 13 12 11 10 9 8 7 6
32 31 30 29 28 27 26 25 24 23 22 21
(-) PTS: Blue, pin 20
86 87 85
87a
86
(+)12V
30
Optional
18
(+) Accessory: Pink, pin 2
Start/Stop Unit
4 3 2 1
(White conn. at
16 15 14 13
steering column)
Cut
5 4 3 2 1
20 19 18 17
(+) Ign. 3 Interrupt:
Brown, pin 17
Cut
87 85
87a
30
(+) 12V:
White,
pin 1
1
Fuse Box
(White conn.
at drivers kick)
(-) Trunk Release
Red, pin 10
Factory Alarm/Door Lock:
Brown, pin 22
White 32-pin connector
(BCM bottom left plug)
(MUX) Door Lock Output: Violet/Brown: 6
(-) Parking Lights Output: Lt. Green/Black: 1
(-) Push-to-Start Output: Lt. Blue/Black: 10
Siren
Hood Pin
Parking Light Interrupt (vehicle side): Blue/White: 1
Parking Light Interrupt (conn. side): Blue: 3
Cut
(-) Parking Lights:
Blue, pin 1
Parking Lights Interrupt:
Black, pin 2
1 2 3 4 5 6
Parking Light
Assembly Switch
1 2 3
5 6 7
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) Trunk Release Output: Red/White: 4
(+) Accessory 1 Output: White: 7
Ignition Interrupt Output: Blue/Black: 9
(+) Siren Output: Brown/Red: 11
(+) Trunk Shunt Input: Orange/Black: 18
(-) Hood Input: Gray: 21
(+) Starter Output: White: 5 & 11
(+) 12V: Red: 6 & 12
(+) Ignition Output: Lt. Green/Red: 7
(+) 12V: Lt. Green: 8
(-) Ground: Black: 10
(+) Trunk Release Actuator:
It is important to check that the
White, pin 4
fuses are positioned correctly. See
Fuse selection on the next page for
more information.
4
ESU
8
(Electrical Supply Unit)
(White conn. at drivers kick)
DS4
DS4+
DS4+ MA3
