Directed DS4+ Installation Manual page 22

Wire Information
Function
Toyota Yaris Sedan (Smart Key) 2016
HS CAN High
HS CAN Low
PTS
Ignition 2 Interrupt [3]
Ignition 3 Interrupt [3]
Brake
Door Lock
Door Lock - W/O OEM Security Pink
12V
Trunk Release Actuator [6]
Trunk Release (for sedan only)
Parking Lights
Parking Lights Interrupt
22
Color Pin Polarity
Green 7 Data
Red 8 Data
Red 17
Pink 3
Brown 17
Blue 2
Brown 22 MUX
6 MUX
White 1
White 4
Green 11
Blue 1
Black 2
Location
Start/Stop unit in steering column.
Start/Stop unit in steering column.
(-) Start/Stop unit in steering column.
Cut Start/Stop unit in steering column.
Cut Start/Stop unit in steering column.
(+) Start/Stop unit in steering column.
Start/Stop unit in steering column.
Start/Stop unit in steering column.
(+) Fuse box in driver kick.
(+) ESU (Electrical Supply Unit) in drivers kick panel.
(-) BCM above drivers kick.
(-) Parking light assembly switch.
Cut Parking light assembly switch.
Connector Information
Color
White
White
White
White
White
White
White
White
White
White
White
White
White
© 2017-02-15 Directed. All rights reserved.
Pins Ref.
24 A
24 A
24 A
32 B
32 B
32 B
32 B
32 B
1 C
8 D
24 E
6 F
6 F
DS4+ MA3
