Directed DS4+ Installation Manual page 10

Fuse selection
To ensure correct functionality of your system, please configure the fuses on your system as follows:
DS4+
10 12
Slide to open
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
2
Function Color
Mazda CX-5 (Smart Key) 2013-2016
HS CAN High White/Black
HS CAN Low Red/Yellow
Accessory 1 Yellow/Green
Accessory 2 Brown/Red
Ignition 1 Lt. Green/Red
Starter Brown/Black
PTS 1 Green/White or Lt. Green/Red
Ignition 2 Interrupt [3] Gray/Red
Ignition 3 Interrupt [3] Violet
Door Lock White/Green
12V White
Trunk Release Actuator [6] Green
Trunk Release White/Blue
Parking Lights Yellow
Parking Lights Interrupt Green
10
22 8
4 4 4 2
Wire Information
DS4
12
Slide to open
2 4
Pin Polarity Location
7 Data Start/Stop unit in steering column.
8 Data Start/Stop unit in steering column.
2 (+) Start/Stop unit in steering column.
14 (+) Start/Stop unit in steering column.
10 (+) Start/Stop unit in steering column.
23 (+) Start/Stop unit in steering column.
20 (-) Start/Stop unit in steering column.
3 Cut Start/Stop unit in steering column.
17 Cut Start/Stop unit in steering column.
12 MUX Driver kick, door harness.
1 (+) Fusebox in driver kick.
2 (+) BCM in left rear quarter panel.
3 (-) Trunk release switch.
3 (-) Parking light assembly switch.
4 Cut Parking light assembly switch.
22 8
4 4 2
Connector Information
Color
White
White
White
White
White
White
White
White
White
White
White
Blue
White
White
White
© 2017-02-15 Directed. All rights reserved.
Pins Ref.
24 A
24 A
24 A
24 A
24 A
24 A
32 B
32 B
32 B
32 C
1 D
18 -
3 -
6 E
6 E
DS4+ MA3
