Directed DS4+ Installation Manual page 13

Fuse selection
To ensure correct functionality of your system, please configure the fuses on your system as follows:
DS4+
10 12
Slide to open
Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
2
Function
Mazda 6 (Smart Key) 2014-2016
HS CAN High
HS CAN Low
Accessory 1
Accessory 2
Ignition 1
Starter
PTS 1
Ignition 2 Interrupt [3]
Ignition 3 Interrupt [3]
Door Lock
12V
Trunk Release Actuator [6]
Trunk Release (for sedan only)
Parking Lights
Parking Lights Interrupt
13
22 8
4 4 4 2
Wire Information
Color
White
Red
Yellow/Green
Brown/Red
Lt. Green/Red
Brown/Black
Green/White or Lt. Green/Red
Gray/Red
Violet
White/Green
White
Green or Brown
Green/Red
Yellow
Green
DS4
12
Slide to open
2 4
Pin Polarity Location
7 Data Start/Stop unit in steering column.
8 Data Start/Stop unit in steering column.
2 (+) Start/Stop unit in steering column.
14 (+) Start/Stop unit in steering column.
10 (+) Start/Stop unit in steering column.
23 (+) Start/Stop unit in steering column.
20 (-) Start/Stop unit in steering column.
3 Cut Start/Stop unit in steering column.
17 Cut Start/Stop unit in steering column.
12 MUX Driver kick, door harness.
1 (+) Fusebox in driver kick.
2 (+) BCM in left rear quarter panel.
1 (-) Trunk release switch.
3 (-) Parking light assembly switch.
4 Cut Parking light assembly switch.
22 8
4 4 2
Connector Information
Color
White
White
White
White
White
White
White
White
White
White
White
Blue
White
White
White
© 2017-02-15 Directed. All rights reserved.
Pins Ref.
24 A
24 A
24 A
24 A
24 A
24 A
32 B
32 B
32 B
32 C
1 D
18 -
4 E
6 F
6 F
DS4+ MA3
