Teldat S.A.
3.2 Description of the microswitches
In the interior of the Atlas 250 routers, you will find a group of SW2 micro-switches. These are identified by the num-
bers '1' to '8' as shown in the below figure. These activate test functions, software loading functions etc. All these mi-
cro-switches are in the OFF position by default. These should not be handled by the user other than to reestablish
the default configuration as described below.
Atlas 250
3 Description of the equipment
9
