Technical Information
The local console is only dis-
playing garbage
The device does not initialize
and the console displays the
WARM-UP text.
The device is very slow in dis-
playing the application prompt.
You have forgotten the pass-
word to access the device
The LAN LED never lights up in
green.
The WAN LED never lights up in
green.
The ISDN LEDs never light up
in either yellow or green.
The LEDS indicate the inter-
faces are established but there
is no connectivity at the data
levels.
A.3 Updating the software and the configurations
Both the BIOS as well as the routing application code and the configurations are stored in the device flash memory.
This is handled as a standard disk unit. The executable codes have a .bin extension and can by updated via FTP us-
ing the Atlas 250 router FTP server, and by XModem through the device local console.
The configurations have a .cfg extension and can only be read and written via FTP. If you wish to make copies of
your configurations, simply obtain the .cfg router file possessed by the router. In the same way, if you wish to use a
configuration, simply overwrite the aforementioned file.
Note
UPDATING THE APPLICATION
The code storage system simulates a standard disk drive unit: you must make sure that the application
file name loaded in the device coincides with that already existing. If this is not so, it is possible that the
loaded code will not automatically activate and the system will continue to execute the code that exis-
ted prior to the updating.
If you always use the same file name, the system will delete the previous code, substitute it with the
new code and activate automatically.
16
Check that the terminal configuration is 9600 8N1.
Check that the console is not in an events process.
Check that the device is not being remotely accessed via telnet.
Check that the terminal has the correct port configured.
Check that the terminal configuration is 9600 8N1.
Check that micro-switch '1' is in the OFF position. In this situation, you may have
to reload the device BIOS and the routing application.
Check that micro-switch '3' is in the OFF position.
Ignore the configuration through micro-switch '5' as explained in the section on mi-
cro-switches.
Check that the rear LINK LED is ON.
Check the Ethernet cable and the connection to the network (you may need a
crossover cable).
Check that the cable you are using is adequate, that the driver is inserted in the
correct position (DTE or DCE).
Check that the configuration is correct (speed, protocol, etc.).
Check that the connection to the bus is correct and that the Sbus terminal switch
is in the correct position.
Check the configuration (routes, IP addresses, serial interface speed, etc).
