A.3.1 Updating using FTP
The Teldat devices have an internal FTP server that is capable of distinguishing if the loading file is from BIOS, an
application or comes from another source. Therefore, the server operation is completely transparent.
Note
By default, the FTP server is located in port 21; through the configuration, you can change the FTP port
server. You must check to make sure you are accessing the correct port. If not, you will not be able to
receive a response from the server.
In order to carry out a code transfer (assuming the server port has not been modified):
• Introduce the login and the password.
• Pass to binary mode through the "binary" command.
• Carry out the transfer through the "put" command.
• Permanently save the loaded file with "quote site savebuffer" command.
• If you want the device to automatically restart and begin executing the new code, you can send the "quote site re-
load on" command. On leaving the FTP session, the device will restart after approximately 30 seconds.
C:\atl>ftp 172.24.78.94
Connected to 172.24.78.94.
220 FTP server ready, 1 active clients of 1 simultaneous clients allowed.
User (172.24.78.94:(none)): root
331 User name accepted, need password.
Password:
230 User login complete.
ftp> dir
200 PORT is set to IP ADDR = 172.24.51.23
150 Data connection open, list transfer in process...
-rwxrwxrwx
-rwxrwxrwx
226 List transfer completed, data connection is closed.
395 bytes received in 0,16 seconds (2,47 Kbytes/sec)
ftp> binary
200 TYPE is set to IMAGE.
ftp> hash
Hash mark printing On (2048 bytes/hash mark).
ftp> put atlas2g.bin
200 PORT is set to IP ADDR = 172.24.51.23
150 Data connection open, file transfer in process...
###########################################################
###########################################################
###########################################################
###########################################################
Atlas 250
- If users have been defined, use the names and passwords for these as login
and password. Updating will be executed or not depending on the user access
levels.
- If there are no defined users, use "root" as login.
- If the password has not been configured, press "intro" .
- If you have the console password configured, insert the same password in or-
der to access the FTP server.
- If you have authentication activated with a RADIUS server, insert the corres-
ponding password.
1 ftp ftp 2163872 Nov 27 2001 ATLAS2G.BIN
1 ftp ftp
PORT = 1964
4727 Nov 27 2001 ROUTER.CFG
PORT = 1965
