Accesso ries

Remote Close Solenoid

Th is accessory is an e lectrically operated solenoid which,
when energized, closes the breaker. It is suitable for control
i nterlock schemes in which manual closi ng capabi l ity would
not be conven ient or would be too slow. It is a n optional ac­
cessory for a m a n u a l l y operated b rea ker, but is required for
an electrically operated breaker. The remote close accessory
is continuously rated and has an anti-pu m p feature which
prevents a motor operated breaker from repeatedly closing
into a fau l t . Closing control voltage must be removed and
re-a pplied for each breaker closure.
This accessory consists of an integ ral e lectronic control mod­
ule and the closing solenoid. When control voltage is applied
to the accessory, the electronic control module a p plies a
single pulse of cu rrent to the solenoid for a pproximately 0.25
seconds to d rive the solenoid before shutting the cu rrent off
to a level of approximately lOmA. Voltage m ust be removed
and re-applied to reclose the breaker, thereby providing the
anti-pump feature.
This pulse approach a llows the accessory to be continuously
rated. Control voltage m u st be removed for 2.5 seconds and
then rea pplied each time the solenoid is to be energized.
Removal of the voltag e for significantly less than 2.5 sec­
onds will not reset the e lectronic control module and prevent
the solenoid from being energ ized. Applied control voltag e
(closed circuit voltag e at breaker terminals 34 and 1 6) must
be 85% to 110% of nominal. The solenoid will not energ ize if
voltage is ramped u p to the accepta ble range. Th ree-cycle
closing time, at nominal voltage, is standard and fulfi lls the
requirements of generator synchronizing.
Table 25.2
Control Power Requirements For Motor Operators
Rated Voltage
Operating
Voltage Range
(50-60 Hz)
53
24 Vdc
2 1 - 2 7 Vdc
48 Vdc
4 1 -
72 Vdc
62 - 80 Vdc
120 Vac
102 - 132 Vac
1 2 5 Vdc
106 - 137 Vdc
CD
240 Vac
204 - 264 Vac
Charging time a p ply to normal voltage only; times may vary a t maxim u m and minimum voltage.
Peak I n rush
(RMS Amps)
30.0
Vdc
18.0
10.0
7.5
8.0
6.0
Table 25.1
Remote Close Solenoid
Catalog Number
SPRCS024
SPRCS048
SPRCS072
SPRCS125
SPRCS120
SPRCS240
Remote close solenoid
Peak Full
Average Amps
Load Amps
14.0
1 1.0
5
7.0
4.5
4.
3.0
4.0
2.0
2.5
1.8
2.5
1.0
Voltage Ratings
Peak Inrush Current
(Amps)
24 Vdc
1 3 2
s o
48 Vdc
6.6
72 Vdc
1 2 5 Vdc
3 . 5
120 Vac
3.0
240 Vac
2.0
Charge Time
Recommended
(Sec) CD
Fuse (Sio-blow)
3
12A, 1 2 SV
3
7A. 1 2 SV
3
5A, 125V
3
4A , 1 25V
3
2 SA, 125V
3
2.SA, 250V
-
25
