Phys ica l Data
Power B reak® I I 800-2000A Drawout Mecha n ical I nterlock
F LUS H
1 . All outline dimensions are the same for manually and electrically operated devices.
2. Dimensions in brackets are in [millimeters].
3. Customer's location far drilling hole far horizontally or vertically interconnected mechanical interlock. See bottom or side view.
