Catalog N umbers
M icroVersaTrip Plus™ and MicroVersaTrip PM™ Tri p U n it Cata log N u m bers
Trip unit type and rating
B2 = Power Break® II E n h a nced MicroVersaTrip
Plus o r PM Trip U n it: 2000A sensor maximum
B3 = Power Break I I Enha nced MicroVersaTrip
Plus o r PM Trip U n it: 3000A sensor maximum
B4 = Power Break I I Enha nced M i c roVersa Trip
Plus o r P M Trip U n it: 4000A sensor maximum
Sensor rating
02 = 200A
04 = 400A
08 = 800A
10 = 1000A
16 = 1600A
2 0 = 2000A
25 = 2 500A
3 0 = 3000A
40 4000A
=
Auxiliary functions
Ll Long time and instantaneous
=
LSI = Long-time, Short-time, instantaneous
LSH = Long-time, Short-ti me, high ra nge instantane
Rating Plug Cata log N u m bers
Device Type
TR Trip unit rating plug
=
All MicroversaTrip Plus
and M icroVersaTrip PM rating plus
02 = 200A
04 400A
=
08 = 800A
10 = 1000A
16 = 1600A
2 0 = 2000A
25 = 2500A
30 = 3000A
40 = 4000A
B2 20 LSI GZI
PM R
!
TR 10 B 800
Replacement or new
R = Replacement trip u n it
(Blank) = New
Trip unit options
Options for MicroVersaTrip PM trip u n its o n ly.
Must select one:
P = Protective relays and communications
M = Metering and commun ications
PM = Protective relays, metering,
and communications
( B lank) = M icroVersaTrip Plus trip u n it
Ground fa ult funcitions
G = G round fa ult
G D = G round fault defeata ble (not U L listed)
GZl = G round fault; ground fault o n ly zone
sel ective interlock
GZ2 = g round fault and short-time selective i nterlock
G DZ2 = G round fault defeata ble (not UL listed):
gound fault and short-time selective interlock
(Blank) = None
100 = 100A 1000 = 1000A
1 5 0 = 1 50A 1200 = 1200A
200 = 200A
1 500 = 1500A
2 2 5 = 2 2 5 A 1600 1600A
=
300 = 300A 2000 = ZOOOA
400 = 400A 2500 = ZSOOA
500 = 500A 3000 = 3000A
600 = 600A 3600 3600A
=
700 = 700A 4000 = 4000A
800 = 800A
Trip unit type
Plus & M icroVersaTrip PM
B = All Enha nced M ic roVersaTrip
trip u n it rating plugs
3 7
