Accessories
Padlock Device (Sta ndard)
Padlocking devices a re standard o n all Power Break® II Cir­
cuit breakers. When the b reaker is in the open position, and
the padlock device is raised at least %", the breaker cannot
be closed mech a n ically or electrically. The device accepts
up to three padlocks with 1/4" to 3/8" dia meter sha nks. The
padlock device meets the EUS ERC req uirement for
padlocking.
I ntegral padlock device
Key I nterlock Provisions
The key i nterlock provision enables the user to mount a
one-to four-cylinder, narrow-faced, Ki rk-type FN customer­
supplied lock on the face of the breaker. The key interlock
provision works in conj unction with the padlock device. The
key interlock extends a lever through the padlock device
when the key is turned to the key removal or bolt extended
position.
Key interlock insta lled on front of the breaker
30
Table 30.1
Key I nterlock Provisions
Catalog Number of
N u m ber Locks
SPK4 1
SPK4 2
SPK4 3
SPK4 4
CD Final digit may be 0, 1, 2, or 3 depending on n u m ber of key removal
positions.
Door I n terlock
The door i nterlock provides interlocking of the circuit b reaker
compartment's hinged door so that the breaker must be in
the "OFF" position before the door can be opened. The door
interlock i s defeata ble with a small tool to a l low a uthorized
access. The catalog num ber of the door interlock is: SPOIL.
D o o r interlock
Kirk Key lock Superior Cat.
Cat. Number Number
KFN00001- CD
S105827Y
KFN00002- CD
S105828Y
KFN00003- CD
S105829Y
KFN00004- CD
S105827-4Y
