3–7 Remote Close Solenoid and
Remote Charge Indication
The remote close solenoid is included with electrically
operated breakers and may be ordered as a factory-
installed option in manually operated breakers. Catalog
numbers and specifications are listed in Table 8.
Remote charge indication provides for remote indication
that the breaker closing springs are charged. Catalog
numbers are TPXCAS and TSXCAS for 800–2000 A and
for 3000–4000 A frames, respectively. The switch is rated
at 15 A for 250 Vac and at 0.5 A for 125 Vdc. Figure 41 is
the wiring diagram for remote charge indication. Figure
42 is the wiring diagram for remote charge indication
with a remote close solenoid.
Catalog No.
TPXCC12S
TPXCC14S
TPXCC08S
* The power source must stay within the rated operating voltage range of the close solenoid from no load to the full peak
current rating of the device.
3–8 Optional Features
Special features may be ordered as specific accessories or
as an integral part of the breaker catalog number. Refer to
the BuyLog®, GEP-1100, for these features.

Limited Close Access Button

This accessory, shown in Figure 43, provides for limited
manual access to the
closed in an emergency for maintenance by inserting a
1
/ -inch diameter pin or rod into the hole in the center of
8
the button. Manually operated breakers must be ordered
with an accessory closing solenoid.
, the auxiliary switch
on
Rated Operating
Voltage Range*, V
120 Vac 102–132
240 Vac 204–264
24 Vdc 19–29
Table 8. Catalog numbers and ratings for the remote close solenoid.
button. The breaker can be
ON
Figure 41. Wiring diagram for remote charge indication.
Figure 42. Wiring diagram for remote charge indication with remote
Current at Max. Maximum
Voltage, A Closing Time, s
3.3 0.083
1.7 0.083
13 0.083
Figure 43. Limited close access button.
18
close solenoid.
Maximum
Operating Time, s
0.050
0.050
0.050
