Teldat S.A.

A.3.1 LAN Connector

RJ45 LAN
A.3.2 WAN Connector
RJ45 WAN
A.3.3 WWAN/Cell Connector (female)
Teldat V Router
RJ45 PIN
1
2
3
4
5
6
7
8
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
ANT
RF in/out
GND
Technical Information
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
29
